Description
t12-958 Mini Intelligent Constant Temperature Soldering Station STM32 OLED Digital Adjustable Solder Iron Portable Welding Tool
Item Description
Name: thermostat soldering station
Model: a package
Voltage: 110-220 v / 50 to 60 hz
Power: 72 w
Package weight: 0.6 KG packing size: 18 * 21 * 10 cm
Heating time: 7 s
Output voltage: 24 (V)
Dimension: 130 * 88 * 38 (mm)
Temperature control range: 50-480 (℃)
Net weight: 0.55 (kg)
Power: 72 (W)
Name: thermostat soldering station
Two models: package
Voltage: 110-220 v / 50 to 60 hz
Power: 72 w
Package weight: 0.6 KG
Packing size: 18 * 21 * 10 cm
Heating time: 7 s
Output voltage: 24 (V)
Dimension: 130 * 88 * 38 (mm)
Temperature control range: 50-480 (℃)
Net weight: 0.55 (kg)
Power: 72 (W)
Name: thermostat soldering station
Three models: package
Voltage: 110-220 v / 50 to 60 hz
Power: 72 w
Package weight: 0.6 KG
Packing size: 18 * 21 * 10 cm
Heating time: 7 s
Output voltage: 24 (V)
Dimension: 130 * 88 * 38 (mm)
Temperature control range: 50-480 (℃)
Net weight: 0.55 (kg)
Power: 72 (W)
About this item
Note: set a 1 K (including head), set two (including two welding head), set three (including three welding head)
Note: the welding head can't work continuously at high temperature, high temperature work easy to damage the welding head!
Ordinary solder melting point is 183 ℃, lead-free solder melting point is 227 ℃, usually welding temperature is 300-380 ℃, 380 ℃ is the dividing line between temperature higher than 380 ℃, welding head oxidation loss soon, seriously affect the life of heater is higher than 380 ℃ temperature display beats, the higher the temperature the greater the beat! Advice within 300-380 ℃ for welding work, most of the work can be completed, under normal temperature beating, will not affect the use!
The soldering station using the soldering iron is a new welding head. Due to the uncertain new welding head resistance temperature jump or error, belongs to the normal phenomenon. After several times use, stability will gradually stable. If you mind, please don't buy.
